APPLICATION: Laser welding of plastics
FHI has a wide assortment of dyes and blends compositions for effective absorption of laser radiation in the visible and near infrared spectral regions. We can submit custom formulations of dyes blends for blocking laser radiation in any desired spectral area. Our visible and NIR dyes have excellent thermal stability which makes them suitable for solid thermoplastic resin formulations and injection molding.
Code FHI λmax, nm Solvent E, L/g.cm Purity, % Melting Point, oC

4168 416 N-methylpyrrolidone(NMP) 57 97 280-284
4602 459 Acetone 51.5 98 237-240
4742 474 Acetone 120 97 188-190
4902 489 Acetone 155.5 98 268-271
5152 515 Acetone 250 98 267-270
5202 520 Acetone 125 98.5 >250
5242 524 Acetone 110 98 267-270
5273 527 Acetone 155 98 245-247
5402 540 Acetone 140 98 205-207
5442 544 Acetone 177 98.5 216-218
5482 548 Acetone 174 98 168-170
5553 555 Acetone 85 98 245-247
5562 556 Acetone 221 98.5 267-269
5832 564 Acetone 115 98.5 196-198
5868 586 N-methylpyrrolidone(NMP) 20 95 256-259
5936 591 Acetone 214 97 288-292
6151 615 Acetone 130 97.5 232-235
6351 635 Acetone 145 97.5 157-160
6736 673 DMF 98.2
6746 674 Benzene 125 98 235-237
6822 682 Acetone 190 98 215-217
6922 692 Acetone 214 98.2 233-235
7002 700 Acetone 155 98.1 212-214
7212 721 Acetone 170 98 215-217
7332 733 Acetone 137 98.2 222-224
7396 739 Chloroform 37 97 >250
74041 740 Chloroform 84 97 348-351
74641 746 Chloroform 82 97 68-71
7676 754 Chloroform 48 97 >250
7568 756 Chloroform 55 97 245-248
7828 782 Acetone 50 95 256-258
78342 783 Chloroform 40 97 124-126
79142 791 Chloroform 53 97 288-290
79542 795 Chloroform 40 98 137-139
80241 802 Chloroform 75 97.5 303-306
80342 803 Chloroform 52 98 247-249
8062 806 Chloroform 500 98.4 256-258
8082 808 Acetone 350 98.5 245-247
80942 809 Chloroform 31.5 97 235-238
82841 828 Chloroform 68 97 300-304
83541 835 Chloroform 66 97 272-275
8402 840 Acetone 292 97 245-247
8506 846 Acetone 38 97 287-291
8472 848 Acetone 330 98.5 264-266
85642 856 Chloroform 60 97 286-290
85942 859 Chloroform 17 96 102-104
86041 860 Chloroform 67 97 >300
8706 864 Acetone 43 97 288-292
8682 868 Acetone 230 98.2 192-194
88242 882 Chloroform 42 97 286-290
8856 885 Acetone 36 97 295-299
8906 890 Acetone 50 97 277-281
89242 892 Chloroform 52 97 248-252
8972 897 Acetone 220 97.5 263-265
9072 907 Acetone 210 98.8 225-228
92043 920 Chloroform 65 97 244-248
92542 925 Chloroform 57 97 312-315
9526 943 Acetone 57 97 284-288
9556 945 Acetone 56 97 289-293
94842 948 Chloroform 44 97 232-234
94931 949 Acetone 20.5 97 144-146
9506 950 Acetone 60 97 299-303
9582 958 Acetone 156.2 97-98 215-219
9606 966 Acetone 52 97 288-292
98911 989 Ethanol 50 98 240-242
99211 992 Acetone 60 97 110-112
10012 1001 Acetone 229 98.5 260-262
10012 1001 Benzene 98.5
10022 1002 Acetone 200 98.6 196-198
10032 1003 Acetone 191 97-98 222-224
10312 1031 Acetone 210 98.5 270-272
105042 1050 Chloroform 47 97 259-262
109642 1096 Chloroform 47 96 228-231
11732 1157 Acetone 140 98 205-207
1570 1498 Chloroform 35 96 195-197
